| Function Type | Semi Automatic |
| Brand | Fiberdox |
| Usage/Application | Splicing Fiber |
| Model No. | T 308X |
| Dimensions | 12x12x12 |
| Return Loss | 0.02 |
| Internal Data Storage | 10000 |
| I Deal In | New and Second Hand |
| Made in korea | Good quality |
2 year warranty 2 battery
Details
| Power supply | AC 100-240V input or DC 12.6V 1.8A |
| Size | 122 x 124 x 138mm (L x W x H) |
| Weight | 1.4kg (with battery : 1.8kg) |
| Splicing Method | Active Alignment DAA(Digitalized Active Alignment) |
| Splice Time | Quick: 6 Sec. / SM Mode: 8 Sec |
| Return Loss | >60 dB |
| Battery | Li-ion 11.1V 5200mAh / 300 cycles (Splicing & Heating) / Storage Temperature : -20~40℃ |
| Average Loss | SM(0.02dB) / MM(0.01dB) / DS(0.05dB) / NZDS(0.05dB) |
| Electrode Lifespan | > 5,000 |
| Applicable Fiber | SM(ITU-T G652 & G.657) / MM(ITU-T G.651) / DS(ITU-T G.653) / NZDS(ITU-T G.655) |
| Cleaved Length | 250Um Coating : 5~16mm / >250Um Coating : 8~16mm |
| Coating Dlameter | 100-3,000um |
| Cladding Diameter | 80-150um |
| Heating Programs | 36 modes (Pre-set: 4 / User set-up: 32) |
| Heating Time | Typical 15s |
| Applicable Sleeve | 20 ~ 60mm |
| Data Output | USB(5Pin Mini-B) |
| Splice Programs | 139 modes (Pre-set: 11 / User set-up: 128) |
| Splice Memory | Splice record : 10,000 / Image : 2,000 |
| Illumination | LED emitting system |
| Monitor | Color 4.3" LCD monitor, with Touch Screen (Tempered Glass) |
| Cameras | Dual CCD camera |
| Magnification | X/Y (Single image): 400x / X&Y (Dual image): 200x |
| Fibre Display | N/A |
| Wind Protection | The max wind speed 15m/s |
| Operating Environment | Altitude: 0-5,000m / Temperature: -20 to 80℃ / Humidity: 0~95%RH (Non Condensing) |
| Storage Condition | Temperature: -20 to 60℃ / Humidity: 0~95%RH |
| Pull Test | 1.96~2.25N (standard) |
| Attenuation Splicing | Range : 0.1dB ~ 20dB |
| Manufacturer | FibreFox |
