An Optilink 10×2 (10 dBm × 2 Outputs) DC Optical Transmitter featuring a compact 4-hour battery backup is a highly efficient, standard-endurance solution designed for CATV and FTTH (Fiber to the Home) networks. It is specifically engineered to handle short-term power fluctuations and brief load-shedding cycles without disrupting your cable signals.
⚙️ Technical Specifications
- Optical Output Power: 10 dBm × 2 Ports (Two independent 10 dBm laser outputs capable of cleanly splitting and driving signals to multiple nodes).
- Operating Wavelength: 1310 nm (Optimized for standard long-distance analog and digital television broadcast over single-mode fiber).
- Operating Voltage: 12V DC input, drawing minimal power to conserve battery life.
- Integrated Battery Backup: Outfitted with a built-in Lithium-ion (Li-ion) battery pack that provides 4 to 5 hours of continuous runtime under full active load.
- Optical Connectors: Dual SC/APC precision ports for low optical return loss.
- Frequency Range: 47 MHz to 860/1000 MHz, ensuring seamless delivery of standard RF cable channels.
🛠️ Key Product Features
- Short-Burst Power Protection: The 4-hour internal backup acts as an efficient mini-UPS, bridging localized power cuts and keeping downstream amplifiers or nodes fully operational.
- Built-in AGC (Automatic Gain Control): Automatically monitors and normalizes incoming RF power levels to output a perfectly stable optical signal, removing the need for manual tweaking.
- Compact Form Factor: Because it uses a smaller internal battery compared to the 14-hour marathon models, this unit features a lighter, more compact aluminum shell.
- Instant Cut-over Mechanics: Detects power failures instantaneously, switching immediately to internal DC battery power with zero drop in signal strength or laser transmission.
